CUDA (aka Compute Unified Device Architecture) is a parallel computing platform and programming model created by NVIDIA and implemented by the graphics processing units (GPUs) that they produce. CUDA gives program developers direct access to the virtual instruction set and memory of the parallel computational elements in CUDA GPUs.
Noyaux CUDA
6144
Processeur graphique famille
The category to which the graphics processor (GPU) belongs e.g. Southern Islands family of Radeon processors (made by AMD), GeForce 600 (made by NVIDIA).
NVIDIA
Processeur graphique
Also known as a graphics processing unit (GPU), this is a specialized electronic circuit designed to rapidly manipulate and alter memory to accelerate the creation of images in a frame buffer intended for output to a display. GPUs are used in embedded systems, mobile phones, personal computers, workstations, and game consoles. Modern GPUs are very efficient at manipulating computer graphics.
GeForce RTX 5070
Vitesse d'horloge du processeur coup de pouce
2542 MHz
Résolution maximale
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
7680 x 4320 pixels
Affichages max par carte graphique
4
Mémoire
Mémoire carte graphique distincte
12 Go
Type de mémoire de l'adaptateur graphique
The type of memory used by the video card. Often a combination of dedicated memory (Video RAM or VRAM) and dynamic system memory is used. UMA stands for Unified Memory Architecture, and is a computer memory architecture that allows the graphics processing unit to share system memory. Other abreviations: RAM = Random Access Memory, SDRAM = synchronous dynamic RAM, DDR = double-data-rate.
GDDR7
Mémoire Bus
Hardware and software that connects the main memory to the memory controller in computer systems. Originally, general-purpose buses like VMEbus and the S-100 bus were used, but to reduce latency, modern memory buses are designed to connect directly to DRAM chips, and thus are designed by chip standards bodies such as JEDEC.
192 bit
Taux de transfert des données
Rate at which data can be transferred MC, expressed in units per second; may vary on network configurations
28 Gbit/s
Connectivité
Type d'interface
PCI Express 5.0
Quantité de ports HDMI
The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
1
Version HDMI
2.1b
Quantité d'interface DisplayPorts
Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.
3
Version de DisplayPort
2.1b
représentation / réalisation
Synthoniseur TV intégré
Device has an in-built TV tuner.
Version DirectX
DirectX is a collection of APIs (application programming interfaces) for easily handling tasks related to game programming on the Microsoft Windows operating system.
12 Ultimate
Version OpenGL
OpenGL (Open Graphics Library) is a specification defining a cross-language cross-platform API for writing applications that produce 3D computer graphics (and 2D computer graphics as well). The interface consists of over 250 different function calls which can be used to draw complex three-dimensional scenes from simple primitives.
4.6
HDCP
High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.
DVI dual-link
A dual-link DVI interface sends data over both of the DVI links to the monitor, and this is how higher resolutions are achieved. With dual-link DVI, a resolution of 2048 x 1536 is possible.
représentation / réalisation
NVIDIA G-SYNC
Édition surcadencée (OC)
Design
Type de refroidissement
The method used to cool the device or to cool the air around the device.
Actif
Technologie de refroidissement
MSI TORX FAN 5.0
Nombre de ventilateurs
The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation).
2 ventilateur(s)
Format
Description des caractéristiques visibles du produit.
Full-Height/Half-Length (FH/HL)
Prêt pour SFF
Couleur du produit
La couleur, p. ex. rouge, bleu, vert, noir, blanc.
Noir
Puissance
Alimentation minimum supportée
The lowest power that is needed.
650 W
Consommation électrique typique
Amount of power used by this model; expressed in watts
250 W
Prises de courant supplementaires
1x 16-pin
Poids et dimensions
Poids
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
774 g
Longueur du produit
The measurement or extent of something from end to end.
236 mm
Profondeur
The distance from the front to the back of something.
